Cone Pulley Pillar Drill Special Model
| Specification | CPPD25SP |
| Capacity | |
| Drilling capacity | 25 mm |
| Spindle | |
| Spindle Travel | 180 mm |
| Spindle Tapper | MT3 |
| No. of Spindle Speed | 8 |
| Spindle Speed Range (RPM) | 130 to 2600 |
| Working Range | |
| Pillar Diameter | 92 mm |
| Pillar Length | 1410 mm |
| Distance from spindle centre to pillar surface (max) | 250 mm |
| Spindle nose to table distance | 660 mm |
| Distance from spindle nose to base distance | 1045 mm |
| Table travel | 480 mm |
| Table size | 330 x 330 mm |
| Base Size | 370 x 580 mm |
| Motor Belt (V – Belt Nos. 1) | B – 52 |
| Electricals | |
| Electric Motor (HP / RPM) | 1 / 1440 |
| Machine Dimension & Weight (Approx.) | |
| Length x Width | 850 x 450 mm |
| Height | 1770 mm |
| Weight | 225 kg. |
Standard Accessories:
- Motor pulley
- Drill drift
- Fine feed attachment
- Machine lamp
Optional Accessories:
- Drill vice
- Drill chuck with Arbour
- Coolant pump with Stand, Tank, Nozzle & Pipe
- Electric motor
- R/F Switch
- Motor v-belt
As improvements are constantly made in our machines the above specifications and dimensions are subject to modify without any prior notice
