Semi & Fully Automatic Hinge Type Bandsaw Machine
| Specification | SAHTB200 | SAHTB250 | SAHTB300 |
| Capacity | |||
| Cutting Capacity – Round | 200 mm | 250 mm | 300 mm |
| Cutting Capacity – Square | 175 mm | 225 mm | 275 mm |
| Saw Blade Dimension (mm) | 3000 x 27 x 0.9 | 3300 x 27 x 0.9 | 3760 x 34 x 1.07 |
| Blade Speed (meter/min) | 20-35-55-75 | 20-35-55-75 | 20-35-55-75 |
| Bundle Cutting Capacity | 200 x 90 mm | 250 x 120 mm | 300 x 170 mm |
| Job Stroke | 210 mm | 260 mm | 310 mm |
| Electricals | |||
| Drive Motor(HP / RPM) | 1.5 / 1440 | 2 / 1440 | 2 /960 |
| Hydraulic Drive Motor(HP / RPM) | 1 / 1440 | 1 / 1440 | 1 / 1440 |
| Coolant Pump Motor(HP / RPM) | 0.15 / 2800 | 0.15 / 2800 | 0.15 / 2800 |
| Tank Capacity | |||
| Hydraulic Tank | 40 ltrs. | 50 ltrs. | 60 ltrs. |
| Coolant Tank | 40 ltrs. | 50 ltrs. | 70 ltrs. |
| Machine Dimension & Weight (Approx.) | |||
| Length x Width | 1910 x 1450 mm | 2200 x 1610 mm | 2400 x 1825 mm |
| Height | 1000 mm | 1100 mm | 1200 mm |
| Weight | 495 kg | 670 kg | 870 kg |
Standard Accessories
- Electric Motors
- Motor V-belt & step pulley
- One piece of bi-metal blade
- Job stopper assembly
- Power driven wire brush
- Automatic feeding system
- Automatic working height control device
- Hydraulic clamping / decamping device
- Hydraulic blade tension device
- Hydraulic blade breakage detector device
- PLC based control system
Optional Accessories
- Variable speed control by A.C. drive
- Job roller stand
- Chip removing wire brush
- Bi-metal blade
- Centralized lubrication system
As improvements are constantly made in our machines the above specifications and dimensions are subject to modify without any prior notice
